| Loại Main | mATX |
| Thương hiệu | MSI |
| Chipset | Intel® B360 |
| Socket | LGA1151 |
| CPU | Intel® 8th Generation Core™ Processors |
| RAM | 4 x DDR4 2666 / 2400 / 2133 MHz up to 64GB |
| Khe cắm mở rộng | • 2 x PCI Express 3.0 x16 Slots • 4 x PCI Express 3.0 x1 Slots |
| Âm thanh | Intel I219-V Gigabit LAN controller |
| Card mạng | Realtek ALC892 Audio Codec |
| Back I/O Ports | • PS/2 Combo Port • VGA Port •USB 3.1 Gen1 • LAN Port • HD Audio Connectors • USB 2.0 Port • USB 3.1 Gen1 |
| Kết nối | 1 x 24-pin ATX main power connector • 1 x 8-pin ATX 12V power connector • 1 x 6-pin ATX PCIe power connector • 5 x SATA 6Gb/s connectors • 1 x USB 3.1 Gen1 connectors (supports additional 2 USB 3.1 Gen1 ports) • 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) • 1 x 4-pin CPU fan connector • 1 x 4-pin water pump fan connector • 5 x 4-pin system fan connectors • 1 x Front panel audio connector • 2 x Front panel connectors • 1 x Series port connector • 1 x Parallel port connector • 1 x 5050 RGB LED strip 12V connector • 1 x TPM module connector • 1 x Thunderbolt Add-on Card Connector • 1 x Chassis Intrusion connector • 1 x Clear CMOS jumper |
| Công nghệ | • DDR4 Boost • Turbo M.2 • PCI-E Steel Armor • Heavy plated heatsinks • Audio Boost |
| Bảo hành | 36 Tháng |
| Phụ kiện đi kèm | Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables - 3 x Screws for M.2 Sockets |
